The idea in a minute
Last time, we learned to print switches by the million . But a switch only knows two things: on, and off . It can't decide anything. So how does a pile of switches add up your shopping, or check a password? The trick is that you don't need a switch to think. You need to arrange them, so the arrangement does the thinking . First, why only on and off ? A bit is a binary digit, 0 or 1, and any switch with two clear states can hold one . In a chip, a low voltage means 0 and a high voltage means 1 . But they're bands, not exact values . For classic five-volt TTL chips, anything under eight tenths of a volt counts as low, and anything over two volts counts as high . And every gate puts out a cleaner signal than it accepts, so noise gets scrubbed off at each step instead of piling up . The maths came first . In 1854, the English mathematician George Boole published rules for reasoning with values that can only be true or false, 1 or 0 . Three operations do most of the work . AND is true only if both inputs are true . OR is true if either one is, and NOT flips it . In 1937, an MIT master's student, Claude Shannon, noticed that switch circuits obey Boole's rules . Put two switches in a row, and the bulb lights only if A and B are both closed: that's AND . Put them side by side, and either one will do: that's OR . His switches were relays, switches flipped by an electromagnet, the workhorses of telephone exchanges . His thesis even sketched a circuit to add binary numbers . The same year, a Bell Labs mathematician, George Stibitz, took two relays from the company's scrap pile home . With strips cut from a tobacco tin, a couple of dry cells and some flashlight bulbs, he built a machine on his kitchen table that added two binary digits . His wife suggested calling it the Model K, for kitchen . Transistors do the same job as relays, with no moving parts, and far faster . And they come in two flavours. The n-type MOSFET from episode five turns on when its gate is high . Its mirror image, the p-type, turns on when its gate is low . Opposite tempers. That's the whole trick. Stack one of each . The p-type connects the output up to the supply, and the n-type connects it down to ground . Both gates are wired to the same input . Input 0: the top one's on, the bottom one's off, so the output is pulled up to 1 . Input 1: the reverse, and the output drops to 0 . That's a NOT gate, also called an inverter . Two transistors, and the answer is always the opposite . Now use four . Put two p-types side by side on top, and two n-types in a row underneath . The only way to pull the output down is for both bottom switches to be on, so the output is 0 only when A and B are both 1 . That's NOT-AND, or NAND . Swap the arrangement, two in a row on top and two side by side below, and you get NOT-OR, or NOR . Add an inverter and you have AND, or OR . Here's the remarkable part . Given enough of them, NAND gates alone can build any other gate, and so can NOR gates alone . Tie a NAND's two inputs together, and it's a NOT . Follow a NAND with a NOT, and it's an AND . Flip both inputs first, and it's an OR . And since AND, OR and NOT can express any rule at all, NAND can too . This isn't just theory. The computer that guided Apollo to the Moon did all its logic with NOR gates, two to a chip . So how do you add? In binary, there are only two digits, so one plus one is written one-zero: put down 0, carry 1 . For two single bits, the sum digit is 1 only when the inputs differ, a gate called exclusive-or . The carry is 1 only when both are 1, which is just AND . Those two gates together are a half adder . Built from NANDs, it's five gates, about twenty transistors . Chain full adders, which also take in a carry, and you can add numbers of any length . That pairing of opposite transistors has a name: CMOS, complementary MOS .
